Descripción del producto
RECURSOS
XB4MW.PDF Specsheet | Descargar |
Camera | ||
---|---|---|
Image Sensor: | 1/3″ CMOS Progressive Scan | |
Min. Illumination: | Color: 0.028 @ ƒ/2.0, B/W: 0 with IR | |
Shutter time: | 1/3 s to 1/10,000 s | |
Lens: | Fixed, 4 mm @ ƒ/2.0 (6 mm option) Angle of view: 82° (4 mm), 55° (6 mm) |
|
Lens Mount: | M12 | |
Day and Night: | IR cut filter with auto switch | |
Wide Dynamic Range: | 120 dB | |
Digital noise reduction: | 3D DNR | |
Compression Standard | ||
Video Compression: | H.264/MJPEG/H.264+ | |
H.264 code profile: | Main profile | |
Video bit rate: | 32Kbps~16Mbps | |
Dual Stream: | Yes | |
Image | ||
Max. Image Resolution: | 2688×1520 | |
Frame Rate: | 20 @ 2688×1520 30 @ 1920×1080, 1280×720 |
|
Image Settings: | Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser | |
ROI: | Yes, 4 regions | |
3D DNR: | Supported | |
Network | ||
Network Storage: | NAS (Support NFS,SMB/CIFS) | |
Alarm Trigger: | Line Crossing, Intrusion Detection, Motion detection, Dynamic analysis, Tampering alarm, Network disconnect , IP address conflict, Storage exception | |
Protocols: | TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP, PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour |
|
System Compatibility: | ONVIF, PSIA, CGI, ISAPI | |
General | ||
Operating Conditions: | -30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing) |
|
Power Supply: | 12 VDC ± 10%, PoE (802.3af) | |
Power Consumption: | Max. 5 W | |
Weather Proof: | IP66 | |
IR Range: | 30 meters | |
Dimensions: | 60.4 mm × 76.9 mm × 139.2 mm (2.4” × 3.0” × 5.5”) | |
Weight: | 500g (1.1 lbs) |
